Network Switch
RIVI Compact 10
Discreet power where space is at a premium
Our most powerful compact switch, with multi-gigabit uplinks and class-leading power in a silent, palm-sized unit.
Key Benefits
Why Choose the RIVI Compact 10
Future-Ready Uplinks
Two multi-gigabit ports keep your network ready for faster broadband and high-bandwidth devices.
Maximum Power, Minimum Size
A class-leading power budget ensures every connected device receives exactly the power it needs.
Place It Anywhere
Desktop, shelf or wall-mount, it fits where larger switches simply cannot.
Completely Silent
Entirely fanless, running in complete silence in any room of your home.
Technical Specifications
8x 2.5G + 2x 10G ports · Fanless · 240 W PoE budget
Performance
- Switching Capacity
- 120 Gbps
- Forwarding Rate
- 89 Mpps
- MAC Address Table
- 16,384 entries
Connectivity
- Multi-Gigabit Ports
- 8x 100/1000/2500 Mbps RJ45
- 10G Uplinks
- 2x 2.5/5/10 Gbps RJ45 + 2x SFP/SFP+
Physical
- Form Factor
- Desktop or wall-mount (1U)
- Dimensions
- 304 x 305 x 44 mm
- Weight
- 3.57 kg
- Cooling
- Fanless (passive)
Power
- PoE Standard
- 802.3af/at/bt (PoE++)
- PoE Budget
- 240 W
- Max Power Consumption
- 245 W
Interested in the RIVI Compact 10?
Speak with a RIVI-certified integrator to discuss how this product fits your space.
